Flow Divider with Cartridge

Flow Divider with Cartridge

Gear-type cartridge flow divider that splits a single inlet flow (P) into two equal outlet streams (A and B) in a 50/50 ratio. It is used wherever two actuators, cylinders, or motors need to be driven in synchrony from a single pump circuit — without the cost or complexity of a dual-pump arrangement.

The valve body houses two matched gear sections which meter the inlet flow, ensuring each output port receives an equal proportion regardless of differences in load pressure between the two circuits. Four flow range variants cover the full range from 2–40 l/min in a compact zinc plated steel block body.

Key Specifications

• Type: Gear-type cartridge flow divider, 50/50 split
• Rated flow: 2–40 l/min (four overlapping range variants)
• Max. operating pressure: 350 bar
• Fluid viscosity: 10–550 mm²/s
• Filtration: ISO code 16/13
• Division: 50/50 (X = 50-50, standard)
• Port P (inlet): 3/8" BSPP (2–20 l/min variants) | 1/2" BSPP (15–40 l/min variant)
• Ports A & B (outlets): 3/8" BSPP (all variants)
• Body material: Zinc plated steel
• Standard seals: NBR 70 Shore A
• External finish: Zinc plated
• Fluid temperature: -20°C to +90°C
