Differential Relief Valve (Cartridge)
A high-capacity differential (sense-area) relief valve rated to 400 bar and 160 l/min. The differential design offers lower cracking pressure sensitivity at high flow — it is the relief valve of choice for high-flow main-line circuits in industrial and mobile plant hydraulics where stable, consistent cracking behaviour is required.
Two setting ranges cover 20–400 bar, and the standard adjustment is a screw with steel cap.
Key Specifications
- Type: Differential cartridge relief valve
- Thread: M32x1.5
- Max. pressure: 400 bar
- Max. flow: 160 l/min
- Setting ranges: Z: 20–200 bar (std 160 bar) | W: 50–400 bar (std 180 bar)
- Cavity code: DO-590.015.14.10
- Adjustment: Screw with steel cap (standard) | Tamper cap | Handknob with locknut
- Seal options: NBR (standard) | Viton on request
- External finish: Zinc plated
- Fluid temperature: -20°C to +90°C
| Thread (P) | Cavity Code | Max. Pressure (bar) | Max. Flow (l/min) | Setting Range | Std Setting (bar) |
| M32x1.5 | DO-590.015.14.10 | 400 | 160 | Z: 20-200 bar | 160 |
| M32x1.5 | DO-590.015.14.10 | 400 | 160 | W: 50-400 bar | 180 |
